GIS 和地图数据提取的验证码处理

美国的县级地籍系统、州政府地理空间门户，查询地块边界、分区规划或洪泛区数据前通常会弹出图片或 OCR 验证码。这些系统大多是老技术栈，换验证码要走长周期审批，所以老验证码一直留着。批量抓取地块、分区、评估值数据前，先处理这道验证码。

GIS 门户常见的验证码类型

提醒一下：表中 USGS 的 reCAPTCHA v2 由 Google 托管脚本，国内网络访问常不稳定，属连通性问题，与识别能力无关。国内政务系统更常见 GeeTest（极验），CaptchaAI 目前支持 GeeTest v3。

Python 实战：地块查询与批量提取

GISDataExtractor 类封装了地块查询、地址搜索和批量提取，验证码识别统一走内部 _solve_captcha 方法。

import requests
import base64
import time
import re

class GISDataExtractor:
    def __init__(self, api_key):
        self.api_key = api_key
        self.session = requests.Session()
        self.session.headers.update({
            "User-Agent": "Mozilla/5.0 (Windows NT 10.0; Win64; x64) AppleWebKit/537.36"
        })

    def lookup_parcel(self, portal_url, parcel_id):
        """Look up parcel data by ID, solving CAPTCHAs as needed."""
        response = self.session.get(
            f"{portal_url}/parcel", params={"id": parcel_id}
        )

        if self._has_image_captcha(response.text):
            captcha_url = self._extract_captcha_url(response.text, portal_url)
            captcha_text = self._solve_captcha(captcha_url)

            # Re-submit with solved CAPTCHA
            response = self.session.post(f"{portal_url}/parcel", data={
                "id": parcel_id,
                "captcha": captcha_text,
                **self._extract_hidden_fields(response.text)
            })

        return self._parse_parcel_data(response.text)

    def search_by_address(self, portal_url, address):
        """Search GIS records by street address."""
        response = self.session.get(
            f"{portal_url}/search", params={"address": address}
        )

        if self._has_image_captcha(response.text):
            captcha_url = self._extract_captcha_url(response.text, portal_url)
            captcha_text = self._solve_captcha(captcha_url)

            response = self.session.post(f"{portal_url}/search", data={
                "address": address,
                "captcha": captcha_text,
                **self._extract_hidden_fields(response.text)
            })

        return self._parse_search_results(response.text)

    def bulk_extract(self, portal_url, parcel_ids, delay=3):
        """Extract data for multiple parcels with rate limiting."""
        results = {}

        for parcel_id in parcel_ids:
            try:
                results[parcel_id] = self.lookup_parcel(portal_url, parcel_id)
            except Exception as e:
                results[parcel_id] = {"error": str(e)}
            time.sleep(delay)

        return results

    def _has_image_captcha(self, html):
        return bool(re.search(
            r'captcha|verification.?image|security.?code',
            html, re.IGNORECASE
        ))

    def _extract_captcha_url(self, html, base_url):
        from bs4 import BeautifulSoup
        from urllib.parse import urljoin
        soup = BeautifulSoup(html, "html.parser")

        img = (
            soup.find("img", attrs={"src": lambda s: s and "captcha" in s.lower()}) or
            soup.find("img", {"id": re.compile(r"captcha", re.I)}) or
            soup.find("img", {"class": re.compile(r"captcha", re.I)})
        )

        if img and img.get("src"):
            return urljoin(base_url, img["src"])
        raise ValueError("CAPTCHA image not found")

    def _solve_captcha(self, captcha_url):
        """Download and solve image CAPTCHA."""
        img_response = self.session.get(captcha_url)
        img_base64 = base64.b64encode(img_response.content).decode("utf-8")

        resp = requests.post("https://ocr.captchaai.com/in.php", data={
            "key": self.api_key,
            "method": "base64",
            "body": img_base64,
            "json": 1
        })
        task_id = resp.json()["request"]

        for _ in range(30):
            time.sleep(3)
            result = requests.get("https://ocr.captchaai.com/res.php", params={
                "key": self.api_key,
                "action": "get",
                "id": task_id,
                "json": 1
            })
            data = result.json()
            if data["status"] == 1:
                return data["request"]

        raise TimeoutError("CAPTCHA solve timed out")

    def _extract_hidden_fields(self, html):
        from bs4 import BeautifulSoup
        soup = BeautifulSoup(html, "html.parser")
        fields = {}
        for inp in soup.select("input[type='hidden']"):
            name = inp.get("name")
            if name:
                fields[name] = inp.get("value", "")
        return fields

    def _parse_parcel_data(self, html):
        from bs4 import BeautifulSoup
        soup = BeautifulSoup(html, "html.parser")

        def text_or_none(node):
            return node.text.strip() if node and node.text else None

        return {
            "parcel_id": text_or_none(soup.select_one(".parcel-id, #parcelId")),
            "owner": text_or_none(soup.select_one(".owner, .owner-name")),
            "address": text_or_none(soup.select_one(".address, .situs")),
            "zoning": text_or_none(soup.select_one(".zoning, .zone-code")),
            "acreage": text_or_none(soup.select_one(".acreage, .area")),
            "assessed_value": text_or_none(soup.select_one(".assessed, .value")),
            "land_use": text_or_none(soup.select_one(".land-use, .use-code"))
        }

    def _parse_search_results(self, html):
        from bs4 import BeautifulSoup
        soup = BeautifulSoup(html, "html.parser")

        def text_or_none(node):
            return node.text.strip() if node and node.text else None

        results = []
        for row in soup.select(".result-row, tr.parcel"):
            results.append({
                "parcel_id": text_or_none(row.select_one(".parcel-id")),
                "address": text_or_none(row.select_one(".address")),
                "owner": text_or_none(row.select_one(".owner"))
            })
        return results


# Usage
extractor = GISDataExtractor("YOUR_API_KEY")

# Single parcel lookup
parcel = extractor.lookup_parcel(
    "https://gis.county.example.gov",
    "12-34-567-890"
)
print(f"Owner: {parcel['owner']}, Zoning: {parcel['zoning']}")

# Bulk extraction
parcels = extractor.bulk_extract(
    "https://gis.county.example.gov",
    ["12-34-567-890", "12-34-567-891", "12-34-567-892"]
)

验证码参数怎么配置

• method=base64 —— 标准图片验证码。
• numeric=1 —— 只含数字时使用。
• min_len / max_len —— 已知字符数范围时限定长度，如 min_len=4、max_len=6。
• language=0 —— 英文 / Latin 字符集。
• textinstructions —— 自定义说明，用于数学验证码或固定格式代码。

JavaScript 版本：按经纬度坐标批量提取

按经纬度网格遍历区域而非按地块 ID 查询时，可以用 GISExtractor 类，验证码识别逻辑与 Python 版本一致。

class GISExtractor {
  constructor(apiKey) {
    this.apiKey = apiKey;
  }

  async extractByCoordinates(portalUrl, lat, lng) {
    const url = `${portalUrl}/identify?lat=${lat}&lng=${lng}`;
    const response = await fetch(url);
    const html = await response.text();

    if (this.hasCaptcha(html)) {
      return this.solveAndExtract(portalUrl, html, { lat, lng });
    }

    return this.parseGISData(html);
  }

  async extractRegion(portalUrl, bounds, gridSize = 0.01) {
    const results = [];
    const { north, south, east, west } = bounds;

    for (let lat = south; lat <= north; lat += gridSize) {
      for (let lng = west; lng <= east; lng += gridSize) {
        try {
          const data = await this.extractByCoordinates(portalUrl, lat, lng);
          if (data.parcelId) results.push(data);
        } catch (error) {
          console.error(`Failed at ${lat},${lng}: ${error.message}`);
        }
        // Rate limit
        await new Promise(r => setTimeout(r, 2000));
      }
    }

    return results;
  }

  hasCaptcha(html) {
    return /captcha|verification.?image|security.?code/i.test(html);
  }

  async solveAndExtract(portalUrl, html, params) {
    const imgMatch = html.match(/src="([^"]*captcha[^"]*)"/i);
    if (!imgMatch) throw new Error('CAPTCHA image not found');

    const imgUrl = new URL(imgMatch[1], portalUrl).href;
    const imgResp = await fetch(imgUrl);
    const buffer = await imgResp.arrayBuffer();
    const base64 = Buffer.from(buffer).toString('base64');

    const submitResp = await fetch('https://ocr.captchaai.com/in.php', {
      method: 'POST',
      body: new URLSearchParams({
        key: this.apiKey,
        method: 'base64',
        body: base64,
        json: '1'
      })
    });
    const { request: taskId } = await submitResp.json();

    for (let i = 0; i < 30; i++) {
      await new Promise(r => setTimeout(r, 3000));
      const result = await fetch(
        `https://ocr.captchaai.com/res.php?key=${this.apiKey}&action=get&id=${taskId}&json=1`
      );
      const data = await result.json();
      if (data.status === 1) {
        const response = await fetch(portalUrl, {
          method: 'POST',
          body: new URLSearchParams({
            ...params,
            captcha: data.request
          })
        });
        return this.parseGISData(await response.text());
      }
    }
    throw new Error('CAPTCHA solve timed out');
  }

  parseGISData(html) {
    return {
      parcelId: html.match(/parcel.?id[^>]*>([^<]+)/i)?.[1]?.trim(),
      zoning: html.match(/zon(?:e|ing)[^>]*>([^<]+)/i)?.[1]?.trim(),
      acreage: html.match(/acreage|area[^>]*>([^<]+)/i)?.[1]?.trim(),
      landUse: html.match(/land.?use[^>]*>([^<]+)/i)?.[1]?.trim()
    };
  }
}

// Usage
const gis = new GISExtractor('YOUR_API_KEY');

// Single coordinate lookup
const data = await gis.extractByCoordinates(
  'https://gis.county.example.gov',
  34.0522, -118.2437
);

// Extract entire region
const region = await gis.extractRegion('https://gis.county.example.gov', {
  north: 34.10, south: 34.00, east: -118.20, west: -118.30
});

批量提取前的检查清单

• 大规模采集前，先确认地图视口、区域过滤条件和分页控件正常。
• 保存标准化坐标请求体和原始响应，方便定位报错步骤。
• 验证码频率突然升高时先暂停批次，别用重试掩盖对端策略变化。

常见故障排查

• 验证码图片损坏：缺会话 cookie，先加载搜索页面再取验证码。
• 识别结果被拒绝：区分大小写，加 case_sensitive=1 参数。
• 门户每次返回不同验证码：与 session 绑定，需在同一 session 内下载并识别。
• 通过后没有地块数据：缺隐藏表单字段，提交前先提取所有隐藏 input。

常见问题

GIS 门户为什么还在用老式图片验证码？

政府 GIS 系统大多建在验证码服务商还不成熟的年代，换验证码要走长周期审批，团队缺乏升级动力。国内政务系统也常是如此。

USGS 这类门户用的是 reCAPTCHA v2，国内网络访问会有问题吗？

reCAPTCHA 依赖 Google 托管脚本，国内访问常不稳定，属连通性问题，与识别能力无关。先确认页面能正常加载，再排查识别环节。

不同县的验证码格式都不一样，要怎么处理？

每个县的验证码实现可能不同。用 textinstructions 参数描述具体格式，比如“5 位大写字母”，识别准确率更高。

批量抓取地块数据时，怎么避免触发验证码频率升高？

控制并发和请求间隔，参考上面的检查清单；频率明显上升时先暂停任务，别靠加大重试硬扛。
